TEFCOLD FSC175H Slimline Glass Door Merchandiser

£555.00

+vat

- +

Brand:

SKU: 30798

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Lock
  • Adjustable shelves
  • Rollers and adjustable feet
  • Self-closing door
  • LED interior light with switch
  • Thermometer
  • Internal stainless steel base
  • Replaceable door gasket

Product description

The slim FSC175H, at only 435mm wide, makes an ideal glass door merchandiser where space is restricted. The unit comes with 4 adjustable shelves (5 shelves in total), bright LED lighting and light canopy to enable branding. The cabinet lets you optimise space and maximise sales.

SPECIFICATION 51 facts · tap for all External W × D × H435 x 505 x 2013 mmWidth435 mmDepth505 mmGross / net weight70 / 64 kgGross weight70 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181008567site
Product code 30798site
Sub title Slimline Glass Door Merchandisercatalogue
Type Single Door Glass Door Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 505 mmsite
External (W×D×H) 435 × 505 × 2013 mmcatalogue
External W × D × H 435 x 505 x 2013 mmsite
Gross / net weight 70 / 64 kgsite
Gross weight 70 kgcatalogue
Height 2013 mmsite
Internal (W×D×H) 357 × 362 × 1410 mmcatalogue
Internal W × D × H 357 x 362 x 1410 mmsite
Packed (W×D×H) 500 × 550 × 2060 mmcatalogue
Packed W × D × H 500 x 550 x 2060 mmsite
Width 435 mmsite

Capacity5

330ml cans 200 pcssite
500ml cans 100 pcssite
Doors 1catalogue
Gross volume 190 litrescatalogue
Shelves 5catalogue

Performance10

Climate class CC2site
Controller Mechanicalsite
Cooling type Fan assistedsite
Defrost type Automaticsite
Max ambient 322 °Ccatalogue
Maximum ambient +32,2°C, 65% RHsite
Refrigerant R600asite
Refrigerant charge 40 gsite
Temperature range 0 to +7site
Thermometer Yessite

Power & energy6

Annual energy consumption 967 kWh/yearsite
Energy consumption 2.65 kWh/24hsite
Energy efficiency index 78 %site
Input power 140 Wsite
Noise level 56 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings8

Canopy D-Shapesite
Castors 2 rollerssite
Exterior finish Whitesite
Feet / legs 2 adjustable feetsite
Interior light LEDsite
Max load per shelf 196site
Reversible doors Nosite
Shelf dimensions 342 x 266site

Other stated facts1

Energy class Fcatalogue
THE WORKING VIEW

Why this single door glass door fridge earns its place

The Tefcold FSC175H is a slimline upright glass-door merchandiser built for sites where floor width is the binding constraint. At just 435 mm wide externally it slots into aisle ends, counter gaps and narrow runs where a standard cabinet will not fit, putting chilled grab-and-go stock on show behind a single self-closing hinged glass door. The white exterior and interior with five white wire shelves keep the display clean and visible.

Defrost is automatic, so the evaporator clears without a manual routine, and the cabinet is run from a mechanical thermostat control. Cooling is on R600a refrigerant. At 967.2 kWh a year (energy class F, EEI 78.0%) it costs about £242 a year to run at 25p/kWh.

Externally the cabinet measures 435 × 505 × 2013 mm (W×D×H) with an internal 357 × 362 × 1410 mm, and it ships crated at 500 × 550 × 2060 mm, so check delivery access against the packed size. It runs from a standard 13-amp socket, and weighs 64 kg net (70 kg gross), making it manageable to position in a tight space.

BEFORE YOU BUY

Questions, answered straight

It is just 435 mm wide externally (435 × 505 × 2013 mm, W×D×H), with an internal 357 × 362 × 1410 mm. It ships crated at 500 × 550 × 2060 mm, so measure your delivery access against the packed size.

It uses 967.2 kWh a year and is rated energy class F (EEI 78.0%). At 25p/kWh that is about £242 a year.

It carries five white wire shelves behind a single self-closing hinged glass door.

Defrost is automatic, so there is no manual routine, and the cabinet runs from a mechanical thermostat control.

No. It runs from a standard 13-amp socket, and at 64 kg net it is straightforward to position.

Yes. Craven Cooling supports its cabinets after installation — call the service team on 01792 732702 to arrange servicing or a fault visit.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 357 x 362 x 1410 mm
External Dimension (WxDxH): 435 x 505 x 2013 mm
Packed Dimension (WxDxH): 500 x 550 x 2060 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Fan assisted
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 40 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.65 kWh/24h
Temperature Range: 0 to +7 °C
Annual Energy Consumption: 967 kWh/year m³
EEI: 78 %
Input Power: 140 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 56 dB(A)

Measures and Content

Cans 330 ml: 200 pcs pcs
Cans 500 ml: 100 pcs pcs
Bottles 330 ml: 100 pcs pcs
Temperature Range: 0 to +7 °C
Climate Class: CC2
Gross / Net Weight: 70 / 64 kg
Gross / Net Volume: 190 / 116 l
Max Ambient: +32,2°C, 65% RH

Design and Material

Door Reversible: No
Shelf Color: White
Shelf Dimensions: 342 x 266
Max load on Shelves: 196 kg/m²
Canopy Type: D-Shape
Feet / Legs: 2 adjustable feet
Castors: 2 rollers
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD FSC175H Slimline Glass Door Merchandiser then please get in touch.
