TEFCOLD SD1140 Glass Door Merchandiser

£1,376.00

+vat

Brand:

SKU: 18979

Energy Arrow

Product summary

  • High efficiency compressor and EC fans
  • Low E glass door – equivalent to triple glazing
  • Fully automatic
  • Fan assisted cooling
  • Adjustable shelves (split level)
  • Adjustable feet
  • LED interior light with switch
  • Thermometer
  • LED Light canopy with switch
  • Replaceable door gasket

Product description

These glass door merchandisers from Staycold are made in South Africa and are designed to their hot environment, their units are able to work in an ambient of up to 40°C. This combined with an excellent build quality has gained them a reputation for long-lasting units that maintain product temperature, especially during the warmer months. High efficiency compressor, intelligent controller, Low E glass (better insulation), LED lighting, EC energy efficient fans on evaporator and condenser all add up to a great energy saving package and low running costs in a premium cabinet.

The TEFCOLD SD1140 is a white double sliding-glass-door merchandiser holding +1 to +10 °C across eight shelves, measuring 1140 × 635 × 2020 mm (W×D×H), running on R290 with a 13 A supply and using about £290 a year in energy at 25p/kWh.

Downloads

SPECIFICATION 38 facts · tap for all External W × D × H1140 x 635 x 2020 mmWidth1140 mmDepth635 mmGross / net weight182 / 180 kgGross weight182 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand TEFCOLDsite
GTIN / EAN 5060482000276site
Product code 18979site
Sub title Glass Door Merchandisercatalogue
Type Double Door Glass Door Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 635 mmsite
External (W×D×H) 1140 × 635 × 2020 mmcatalogue
External W × D × H 1140 x 635 x 2020 mmsite
Gross / net weight 182 / 180 kgsite
Gross weight 182 kgcatalogue
Height 2020 mmsite
Internal (W×D×H) 1050 × 515 × 1380 mmcatalogue
Internal W × D × H 1050 x 515 x 1380 mmsite
Packed (W×D×H) 1136 × 650 × 2110 mmcatalogue
Packed W × D × H 1136 x 650 x 2110 mmsite
Width 1140 mmsite

Capacity3

Doors 2catalogue
Gross volume 890 litrescatalogue
Shelves 8catalogue

Performance8

Climate class 5site
Defrost type Automatic / Off Cyclesite
Max ambient 40 °Ccatalogue
Maximum ambient +40°C, 40% RHsite
Refrigerant R290site
Refrigerant charge 150 gsite
Temperature range +1 to +10site
Thermometer Yessite

Power & energy5

Annual energy consumption 1160 kWh/yearsite
Energy consumption 3.18 kWh/24hsite
Input power 637 Wsite
Noise level 57 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Whitesite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this double door glass door fridge earns its place

The SD1140 is an upright double-door glass merchandiser finished in white inside and out, built to put chilled stock in front of customers. Two sliding glass doors front eight shelves, so a full column of drinks, grab-and-go or packaged chilled lines stays on show while the glass keeps the cold in. It is the kind of cabinet that earns its floor space through impulse visibility rather than back-of-house storage.

In use it holds +1 to +10 °C, with automatic off-cycle defrost keeping the coils clear without manual intervention. It carries climate class 5, so it holds its temperature in demanding, warmer rooms, and draws 637 W of input power for an energy class D rating. Running cost works out at about £290 a year in energy at 25p/kWh, and it registers 57 dB in operation.

For installation the cabinet is 1140 × 635 × 2020 mm (W×D×H) and weighs 182 kg gross, so plan the delivery route and lifting help in advance. The sliding doors need no swing clearance, which suits tight aisles, and internal space runs to 1050 × 515 × 1380 mm. It runs on a 220-240 V / 50 Hz single-phase supply drawing 13 A, and uses R290 refrigerant with a 150 g charge.

BEFORE YOU BUY

Questions, answered straight

The cabinet is 1140 mm wide, 635 mm deep and 2020 mm high, and weighs 182 kg gross. Measure your access route and arrange lifting help, as the packed unit is 1136 × 650 × 2110 mm.

It runs at +1 to +10 °C, which suits chilled drinks and packaged grab-and-go stock. Automatic off-cycle defrost keeps the coils clear without manual defrosting.

At an input power of 637 W it uses about £290 a year in energy at 25p/kWh, on an energy class D rating. Your actual cost depends on your tariff and how often the doors are opened.

It runs on a 220-240 V / 50 Hz single-phase supply and draws 13 A, so it connects to a standard commercial socket.

It has eight shelves behind two sliding glass doors, and it registers 57 dB in operation.

Yes. It uses R290 refrigerant with a 150 g charge, and Craven Cooling handles servicing and support — call the team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1050 x 515 x 1380 mm
External Dimension (WxDxH): 1140 x 635 x 2020 mm
Packed Dimension (WxDxH): 1136 x 650 x 2110 mm

Cooling and Functions

Type of Defrost: Automatic / Off Cycle
Refrigerant: R290
Refrigerant Charge: 150 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 3.18 kWh/24h
Temperature Range: +1 to +10 °C
Annual Energy Consumption: 1160 kWh/year m³
Input Power: 637 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 57 dB(A)

Measures and Content

Temperature Range: +1 to +10 °C
Climate Class: 5
Gross / Net Weight: 182 / 180 kg
Gross / Net Volume: 890 / l
Max Ambient: +40°C, 40% RH

Design and Material

Exterior Finish: White
Interior Finish: White
Interior Light: LED
If you have any questions about the TEFCOLD SD1140 Glass Door Merchandiser then please get in touch.
