TEFCOLD Galaxy+ GPF3D White Glass Door Freezer

£7,492.00

+vat

Brand:

SKU: 48601

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Adjustable shelves
  • Adjustable feet
  • Vertical LED interior light with switch
  • Thermometer
  • Replaceable door gasket
  • Epos Ticket Strips
  • Heated glass door to prevent condensation
  • Triple glazed insulated glass

Product description

White glass door freezer for great product presentation

The popular Galaxy+ range of freezers offers great product presentation with its stunning design and adjustable shelves, alongside heated glass doors. This allows for multiplexing and allows you to make the most of the space you have available (multiplexing kit required).

The TEFCOLD Galaxy+ GPF3D is a white triple-door upright glass door freezer holding -21 to -18 °C behind three hinged heated glass doors, with 3.2 m² of display area, R290 refrigerant and D energy class drawing about £3230 a year at 25p/kWh.

SPECIFICATION 46 facts · tap for all External W × D × H2343 x 751 x 2005 mmWidth2343 mmDepth751 mmGross / net weight488 / 463 kgGross weight488 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181730246site
Product code 48601site
Sub title Glass Door Freezercatalogue
Type Triple Door Upright Glass Door Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 751 mmsite
External (W×D×H) 2343 × 751 × 2005 mmcatalogue
External W × D × H 2343 x 751 x 2005 mmsite
Gross / net weight 488 / 463 kgsite
Gross weight 488 kgcatalogue
Height 2005 mmsite
Internal (W×D×H) 2343 × 520 × 1386 mmcatalogue
Internal W × D × H 2343 x 520 x 1386 mmsite
Packed (W×D×H) 2600 × 850 × 2390 mmcatalogue
Packed W × D × H 2600 x 850 x 2390 mmsite
Width 2343 mmsite

Capacity3

Display area 3.2 m²site
Gross volume 2468 litrescatalogue
Shelves 12catalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automatic, hot gassite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 2×150 gsite
Temperature range -21 to -18site
Thermometer Yessite

Power & energy6

Annual energy consumption 12921 kWh/yearsite
Energy consumption 35.4 kWh/24hsite
Energy efficiency index 46.5 %site
Input power 2212 Wsite
Noise level 65 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Exterior finish Whitesite
Feet / legs Adjustable Feetsite
Interior light LEDsite
Max load per shelf 160site
Reversible doors Nosite
Shelf dimensions 5x 400mmsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this triple door upright glass door freezer earns its place

The TEFCOLD Galaxy+ GPF3D is a three-door upright glass door freezer in a white finish, built to hold frozen stock at eye level behind full-height glass. Three hinged heated glass doors give 3.2 m² of display area, putting frozen lines in front of customers without the cabinet being opened. The heated glass is designed to stay clear, so the merchandising keeps working through the trading day.

The cabinet runs between -21 and -18 °C under electronic control, with automatic hot-gas defrost that clears the evaporator without manual intervention. It sits in the D energy class with an energy efficiency index of 46.5%, and at 12,921 kWh a year that works out at about £3230 a year at 25p/kWh. Sound output is rated at 65 dB, and it carries climate class 3 for a normal indoor retail environment.

It arrives crated at 2600 × 850 × 2390 mm and weighs 488 kg gross, 463 kg net, so plan the delivery route and floor loading before it lands. Power is a 220–240 V supply drawing up to 16 A with a 2212 W input, so a dedicated circuit is worth specifying. Cooling uses R290 hydrocarbon refrigerant with a 150 g charge.

BEFORE YOU BUY

Questions, answered straight

It runs from -21 to -18 °C under electronic control, suited to fully frozen stock. Automatic hot-gas defrost keeps it clear without manual defrosting.

It is rated at 12,921 kWh a year, energy class D with an efficiency index of 46.5%, which is about £3230 a year at 25p/kWh. Your actual cost depends on your tariff and how often the doors are opened.

A 220–240 V supply drawing up to 16 A, with a 2212 W input. A dedicated circuit is recommended.

It ships crated at 2600 × 850 × 2390 mm and weighs 488 kg gross, so check the delivery route and floor loading before it arrives.

R290 hydrocarbon refrigerant with a 150 g charge — a low-GWP natural refrigerant.

Yes, we service and maintain commercial refrigeration. Call 01792 732702 to arrange a service visit or set up a maintenance contract.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 2343 x 520 x 1386 mm
External Dimension (WxDxH): 2463 x 751 x 2005 mm
Packed Dimension (WxDxH): 2600 x 850 x 2390 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic, hot gas
Refrigerant: R290
Refrigerant Charge: 2×150 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 35.4 kWh/24h
Temperature Range: -21 to -18 °C
Annual Energy Consumption: 12921 kWh/year m³
EEI: 46.5 %
Input Power: 2212 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 65 dB(A)

Measures and Content

Temperature Range: -21 to -18 °C
Climate Class: 3
Gross / Net Weight: 488 / 463 kg
Gross / Net Volume: 2468 / 1300 l
Max Ambient: +25°C, 60% RH
Total Display Area: 3.2 m² m²

Design and Material

Door Reversible: No
Shelf Color: White
Shelf Dimensions: 5x 400mm
Max load on Shelves: 160 kg/m²
Feet / Legs: Adjustable Feet
Exterior Finish: White
Interior Finish: White
Interior Light: LED
If you have any questions about the TEFCOLD Galaxy+ GPF3D White Glass Door Freezer then please get in touch.
