Elcold FOCUS 106 GREY Sliding Curved Glass Lid Chest Freezer

£715.00

+vat

Brand:

SKU: 53301

Energy Arrow

Product summary

  • Defrost drain
  • Static cooling
  • LED interior light with switch
  • Castors
  • Frameless curved sliding lids
  • Fan assisted condenser for energy efficiency
  • Includes full set of baskets

Product description

Sliding Curved Glass Lid Chest Freezer

Elcold’s Focus premium chest freezer is the preferred choice for leading ice cream and frozen food companies. With its sleek design, energy efficiency, and durability, it stands out. The frameless curved sliding lids and internal LED lighting provide an excellent display. Castors come standard, making it easy to move.

The Elcold FOCUS 106 is a grey/white sliding glass-lid display chest freezer offering 270 litres gross (193 litres net), holding -23 to -16 °C with static cooling on R290, manual defrost and mechanical control at energy class D, for about £154 a year at 25p/kWh.

SPECIFICATION 43 facts · tap for all External W × D × H1050 x 650 x 850 mmWidth1050 mmDepth650 mmGross / net weight58 / 54 kgGross weight58 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand Elcoldsite
GTIN / EAN 5708181737283site
Product code 53301site
Sub title Sliding Curved Glass Lid Chest Freezercatalogue
Type Display Chest Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 650 mmsite
External (W×D×H) 1050 × 650 × 850 mmcatalogue
External W × D × H 1050 x 650 x 850 mmsite
Gross / net weight 58 / 54 kgsite
Gross weight 58 kgcatalogue
Height 850 mmsite
Internal (W×D×H) 900 × 500 × 699 mmcatalogue
Internal W × D × H 900 x 500 x 699 mmsite
Packed (W×D×H) 1100 × 760 × 880 mmcatalogue
Packed W × D × H 1100 x 760 x 880 mmsite
Width 1050 mmsite

Capacity1

Gross volume 270 litrescatalogue

Performance10

Climate class 4site
Controller Mechanicalsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 75 gsite
Temperature range -23 to -16site
Thermometer Yessite

Power & energy6

Annual energy consumption 618 kWh/yearsite
Energy consumption 1.69 kWh/24hsite
Energy efficiency index 43.3 %site
Input power 199 Wsite
Noise level 40 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings4

Castors Castorssite
Exterior finish White, Greysite
Interior light LEDsite
Lock Nosite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this display chest freezer earns its place

The FOCUS 106 is a display chest freezer with a sliding glass lid, finished in grey and white for frozen retail display. It offers 270 litres gross and 193 litres net, putting frozen lines on show through the lid so customers can browse and self-serve while the stock stays merchandised in one cabinet.

Day to day it holds -23 to -16 °C using static cooling under mechanical control, with manual defrost — so plan a periodic switch-off to clear ice rather than relying on an automatic cycle. It runs on natural R290 refrigerant with a 75 g charge, draws 199 W, and is rated energy class D at 616.9 kWh a year, which is about £154 a year at 25p/kWh. The interior is lined in hammered aluminium.

For installation, the cabinet measures 1050 × 650 × 850 mm (W×D×H) externally and ships packed at 1100 × 760 × 880 mm (W×D×H), so check delivery access against the crated size. Internal space is 900 × 500 × 699 mm (W×D×H), gross weight is 58 kg (54 kg net), and it runs from a standard 220-240 V, 13 amp supply.

BEFORE YOU BUY

Questions, answered straight

It holds -23 to -16 °C using static cooling under mechanical control, with manual defrost. That suits frozen retail lines on display.

It is rated at 616.9 kWh a year, energy class D, which is about £154 a year at 25p/kWh. Input power is 199 W.

Gross volume is 270 litres and net volume is 193 litres, with a hammered aluminium interior.

It is 1050 × 650 × 850 mm (W×D×H) externally and ships packed at 1100 × 760 × 880 mm (W×D×H). Check the crated size and 58 kg gross weight against your access route.

It runs on natural R290 refrigerant with a 75 g charge and has manual defrost, so plan a regular switch-off to clear ice build-up.

Yes. Our engineers service these cabinets across the UK — call 01792 732702 to arrange servicing or installation advice.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 900 x 500 x 699 mm
External Dimension (WxDxH): 1050 x 650 x 850 mm
Packed Dimension (WxDxH): 1100 x 760 x 880 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R290
Refrigerant Charge: 75 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.69 kWh/24h
Temperature Range: -23 to -16 °C
Annual Energy Consumption: 618 kWh/year m³
EEI: 43.3 %
Input Power: 199 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 40 dB(A)

Measures and Content

Temperature Range: -23 to -16 °C
Climate Class: 4
Gross / Net Weight: 58 / 54 kg
Gross / Net Volume: 270 / 193 l
Max Ambient: +30°C, 55% RH

Design and Material

Castors: Castors
Exterior Finish: White, Grey
Interior Finish: White, Grey
Interior Light: LED
Lock: No
If you have any questions about the Elcold FOCUS 106 GREY Sliding Curved Glass Lid Chest Freezer then please get in touch.
